Cable bracket with Cu crossbar Rd 8−10 mm
Type 113 B-Z16
|Item no. 5412706
|EAN 4012195459071
Item no. / Type
5412706 / 113 B-Z16
Cable dimensions
16 mm round
Smallest selling unit: 100 piece
100piece
piece
Description
113/BZ...: Cable bracket with crossbar
• With female thread M8 or through hole for wood screws
• For flat conductor FL30
• Sliding crossbar for quick mounting
• With female thread M8 or through hole for wood screws
• For flat conductor FL30
• Sliding crossbar for quick mounting
Technical data
Technical data
| Cable dimensions | 16 mm round |
|---|---|
| Holder fastening type | Drill hole with M-thread |
| High voltage-resistant, insulated version | no |
| Material of the crossbar | Die-cast zinc |
| Material of the base | Die-cast zinc |
| Conductor fastening type | With screw clip |
| Use in Ex area | yes |
| Material of the holder | Die-cast zinc |
| Fit | 16 mm rund mm |
| Dimension | 16mm |
| Surface | galvanised |
| Material | Die-cast zinc |
Environmental Data
0,2537 kg CO2e / 1 PieceCO2 Footprint (GWP) Cradle-to-Gate
| CO2 Footprint (GWP) Cradle-to-Gate | 0,2537 kg CO2e / 1 Piece |
|---|---|
| CO₂ Footprint (GWP) | 0,2537 kg CO₂e |
| Determination date of CO2 value | 2025-05-21T00:00:00.000+0200 |
| Declared Unit (LCA) | Units |
| Declared Unit Quantity (LCA) | 1 |
