UP Quick-Fix

UP Quick-Fix

Type ZU 60-QF
|
Item no. 2003740
|
EAN 4012196700806
Show all variants
Item no. / Type
2003740 / ZU 60-QF

Smallest selling unit: 25 piece

piece

Description

Quick fixing through clamping of flush-mounted device boxes Ø 60 mm, instead of plastering or sticking.

For openings with a diameter of 80 mm. Not suitable for the use with thin plaster.
  • Halogen-free; without chlorine, fluorine and bromine
  • Flame resistant 650 °C
  • Communautés Européennes, EC declaration of conformity according to EC directives
  • Diameter 60 mm
  • CO₂ footprint (PCF)
  • Packaging made entirely from recycled cardboard

Technical data

Technical data

Diameter60 mm
Halogen-freeyes
Diameter, interior60 mm
ROHS-conformantyes
Flame-resistantacc. to VDE 0471/IEC 60695-2-11, test temperature 650°C
DimensionØ60mm
MaterialPolypropylene
ColourSignal red
Type of accessoryMiscellaneous
Suitable for cavity wall boxno
Product seriesWIN Series

Environmental Data

0,0224 kg CO2e / 1 PieceCO2 Footprint (GWP) Cradle-to-Gate
Packaging made completely from recycled cardboard.yes
CO2 Footprint (GWP) Cradle-to-Gate0,0224 kg CO2e / 1 Piece
CO₂ Footprint (GWP)0,0224 kg CO₂e
Determination date of CO2 value2025-05-14T00:00:00.000+0200
Declared Unit (LCA)Units
Declared Unit Quantity (LCA)1

Downloads

0 selected

Data sheet (1)
Catalogues & Flyers (2)
Declarations (2)
Instructions and Aid (1)
Product images (2)
Tender specifications (1)

Variants

ZU 60-QF
Item no.
2003740
