Trunking connector and joint cover

Trunking connector and joint cover

Type GK-KS45-1RW
|
Item no. 6113020
|
EAN 4012196419111
Show all variants
Item no. / Type
Colour

Smallest selling unit: 6 piece

piece

Description

Joint cover for the bases of the Rapid 45-2 device installation trunking to hide cut edges and provide a perfect connection of the trunking segments. The joint covers are attached. Suitable for trunking width 100 mm and 165 mm.
  • Verband der Elektrotechnik, Elektronik, Informationstechnik e.V., Germany
  • Communautés Européennes, EC declaration of conformity according to EC directives
  • UKCA declaration of conformity
  • CO₂ footprint (PCF)
  • Packaging made entirely from recycled cardboard

Technical data

Dimensions

Length15 mm
Width55 mm
Height27 mm

Technical data

Halogen-freeyes
Protection ratingIP40
Protection rating IK codeIK08
for duct width100,17 mm
for trunking height53 mm
ShapeSymmetrical
Version forTrunking cut cover
Fastening typeSlide (before mounting)
ROHS-conformantyes
Cover width45 mm
Permitted temperature range, min.-15 °C
Permitted temperature range, max.60 °C
Dimension168x55x15
MaterialPolycarbonate/Acrylnitrile-butadiene-styrene
ColourPure white; RAL 9010
Product seriesRapid 45®

Environmental Data

0,0566 kg CO2e / 1 PieceCO2 Footprint (GWP) Cradle-to-Gate
Packaging made completely from recycled cardboard.yes
CO2 Footprint (GWP) Cradle-to-Gate0,0566 kg CO2e / 1 Piece
CO₂ Footprint (GWP)0,0566 kg CO₂e
Determination date of CO2 value2025-05-14T00:00:00.000+0200
Declared UnitUnits
Declared Unit Quantity1

Downloads

0 selected

Data sheet (1)
Catalogues & Flyers (1)
Declarations (3)
Certificates (1)
Instructions and Aid (2)
Product images (2)
3D data downloads (1)
Tender specifications (1)

Variants

Colour
GK-KS45-1SW
Item no.
6113023
Colour
Jet black; RAL 9005
GK-KS45-1RW
Item no.
6113020
Colour
Pure white; RAL 9010
GK-KS45-1LGR
Item no.
6113022
Colour
Light grey; RAL 7035
GK-KS45-1AL
Item no.
6113024
Colour
aluminium
