Height adjustment bracket for installation in UZD250 for one round cassette
Type NW 250 RK
Item no. 7410552
EAN 4012195432777
Item no. / Type
7410552 / NW 250 RK
Smallest selling unit: 1 piece
1piece
piece
Description
Height adjustment bracket to mount the round height-adjustable cassettes in the underfloor box, type UZD250.
With all the components necessary for mounting and height adjustment.
With all the components necessary for mounting and height adjustment.
Technical data
Technical data
| Decouplable | yes |
|---|---|
| Suitable for cavity floor installation | no |
| Suitable for raised floor installation | no |
| Heavy-duty version | no |
| Approvals | VDE |
| Cover version | Round |
| ROHS-conformant | yes |
| Surface | Strip galvanised |
| Material | Steel |
| Product series | UZD Underfloor junction box |
Dimensions
| Dimension h | 94 mm |
|---|
Environmental Data
4,9672 kg CO2e / 1 PieceCO2 Footprint (GWP) Cradle-to-Gate
| CO2 Footprint (GWP) Cradle-to-Gate | 4,9672 kg CO2e / 1 Piece |
|---|---|
| CO₂ Footprint (GWP) | 4,9672 kg CO₂e |
| Determination date of CO2 value | 2025-05-14T00:00:00.000+0200 |
| Declared Unit | Units |
| Declared Unit Quantity | 1 |
