Sprint screw, with Torx 5.6 | Countersunk head | 3 | 15

Sprint screw, with Torx

Item no. 3198193 | EAN 4012195797593

Item no. / Types

Head diameter

Head shape	Countersunk head

Dimension D

Dimension L

Product description

Product description

Hardened steel, electrogalvanised and Hostaflon-coated. Countersunk head with T bit (six lobe head), sizes Ø 3 mm T10, Ø 3.5 mm T15, Ø 4 and 4.5 mm T20, Ø 5 mm T25.

The use of Sprint screws leads to considerably reduced screw-in times compared with standard screws. This noticeable advantage comes from the point with the first thread, which leads on to the double thread beyond.

Areas of use: wood, chipboard, Rigips panels, plastic anchors.

Technical data

Technical data

Dimension	3x15mm
Dimension D	3 mm
Dimension L	15 mm
Hardened	yes
Head diameter	5,6 mm

Head shape	Countersunk head
Length	15 mm
Material	Steel
Screw system	Torx
Surface	Electrogalvanized

All types

All types

Types	Head diameter	Head shape	Dimension D	Dimension L	Item no.
4759T 3.0x15	5.6 mm	Countersunk head	3 mm	15 mm	3198193
4759T 3.0x25	5.6 mm	Countersunk head	3 mm	25 mm	3198197
4759T 3.0x30	5.6 mm	Countersunk head	3 mm	30 mm	3198199
4759T 3.5x50	6.5 mm	Countersunk head	3.5 mm	50 mm	3198231
4759T 4.0x30	7.5 mm	Countersunk head	4 mm	30 mm	3198243
4759T 4.0x40	7.5 mm	Countersunk head	4 mm	40 mm	3198247
4759T 4.0x50	7.5 mm	Countersunk head	4 mm	50 mm	3198251
4759T 5.0x50	9.2 mm	Countersunk head	5 mm	50 mm	3198284
4759T 6.0x60	11 mm	Countersunk head	6 mm	60 mm	3198322
